SHINKAWA VM-701B/ALY/TB1 Vibration & Displacement Monitor Module PCB Card
Product Overview
WAVETECH MARITIME supplies SHINKAWA VM-701B/ALY/TB1 Vibration & Displacement Monitor Module PCB Card for rotating machinery condition monitoring and vibration monitoring systems.
- Brand: SHINKAWA
- Model: VM-701B
- Configuration: /ALY/TB1
- Product Type: Vibration / Displacement Monitor Module
The SHINKAWA VM-701B/ALY/TB1 is a Vibration / Displacement Monitor Module from the SHINKAWA VM-7 monitoring system. The VM-701B is designed for monitoring vibration and displacement-related parameters in rotating machinery, while the /ALY configuration provides analysis functionality. The /TB1 configuration includes specified transducer input, recorder output and contact output terminal-block plugs. The module is suitable for integration into VM-7 series machinery condition monitoring systems. WAVETECH MARITIME supplies this SHINKAWA monitoring module for marine and industrial automation applications.
Key Features
- Brand: SHINKAWA
- Model: VM-701B
- Configuration: /ALY/TB1
- Product Type: Vibration / Displacement Monitor Module
- Series: VM-7
- Analysis Function: Included with /ALY configuration
- Monitor Function: Vibration and displacement monitoring
- Recorder Outputs: 4 output points
- Recorder Output Range: 1–5V, 4–20mA, 0–5V or 0–10V
- Contact Outputs: 6 relay outputs
- Contact Type: Dry contact, SPDT
- Transducer Power Supply: -24VDC ±10% for proximity transducer; +24VDC ±10% constant-current supply for piezoelectric transducer
- Operating Temperature: 0 to +65°C
- Storage Temperature: -30 to +85°C
- TB1 Accessories: Transducer input terminal-block plugs, recorder output terminal-block plugs and contact output terminal-block plug
- Application: Rotating Machinery Condition Monitoring
- Brand: SHINKAWA
- Model: VM-701B/ALY/TB1
- Condition: Used
- Application:
- Marine Automation Systems
- Rotating Machinery Monitoring
- Vibration Monitoring Systems
- Displacement Monitoring
- Turbine Monitoring Systems
- Machinery Condition Monitoring
- Shaft Vibration Monitoring
- Industrial Monitoring Systems
- VM-7 Series Replacement Modules
- Marine Engine and Machinery Monitoring
- Availability: Subject to stock confirmation
