SHINKAWA ELECTRIC VM-3D2 Thrust Monitor Module
Product Overview
WAVETECH MARITIME supplies SHINKAWA ELECTRIC VM-3D2 Thrust Monitor Module for axial displacement and thrust monitoring of rotating machinery.
- Brand: SHINKAWA ELECTRIC
- Model: VM-3D2
- Product Type: Thrust / Axial Displacement Monitor Module
- Series: VM-3 Series
The SHINKAWA ELECTRIC VM-3D2 is a thrust and axial displacement monitor module from the SHINKAWA VM-3 series. It receives signals from eddy-current proximity probes to monitor rotor axial displacement in rotating machinery. The module provides monitoring and alarm functions for thrust-related conditions and is used in machinery protection and condition monitoring applications. Documented configurations include VM-3D2/99B2020020, including versions with a -40 to +40 mils (-1 to +1 mm) measurement range. WAVETECH MARITIME supplies SHINKAWA ELECTRIC VM-3D2 monitoring modules for marine and industrial automation applications.
Key Features
- Brand: SHINKAWA ELECTRIC
- Model: VM-3D2
- Product Type: Thrust / Axial Displacement Monitor Module
- Series: VM-3 Series
- Sensor Input: Eddy-current proximity probe
- Monitoring: Rotor axial displacement / thrust
- Documented Measurement Range: -40 to +40 mils / -1 to +1 mm
- Analog Output: 4–20 mA
- Relay Outputs: Alert / Danger alarm contacts
- Sensor Fault Detection: Probe fault monitoring
- Mounting: Plug-in card for VM-3 series chassis
- Documented Configuration: VM-3D2/99B2020020
- Origin: Japan
- Brand: SHINKAWA
- Model: VM-3D2
- Condition: Used
- Application:
- Marine Automation Systems
- Thrust Monitoring Systems
- Axial Displacement Monitoring
- Turbine Monitoring
- Rotating Machinery Monitoring
- Machinery Protection Systems
- Steam and Gas Turbine Monitoring
- Compressor Monitoring
- Marine Engine Monitoring
- Industrial Machinery Monitoring
- Availability: Subject to stock confirmation
