SCHOTTEL F-U Converter DZE-3 V1.2 ID-NR 1099146 PCB Card

The SCHOTTEL DZE-3 ID-NR 1099146 is an f/U converter and RPM registration PCB used in SCHOTTEL electronic systems. It converts rotational-speed pulse frequency into an analog voltage signal and provides switching functions based on engine speed for applications including speed indication, speed overlap and control of clutches, brakes and gears. SCHOTTEL documentation specifies a 24 V DC supply, 0.5–500 Hz input range and standardized 0–10 V analog voltage output. WAVETECH MARITIME supplies this SCHOTTEL DZE-3 PCB card for compatible marine propulsion and automation systems.

• Brand: SCHOTTEL
• Model: DZE-3
• Version: V1.2
• ID Number: 1099146
• Product Type: F-U / Frequency-to-Voltage Converter PCB
• Function: RPM / Speed Signal Conversion
• Power Supply: 24 V DC
• Input Frequency Range: 0.5–500 Hz
• Maximum Input Frequency: 1.5 kHz
• Standardized Analog Output: 0–10 V
• Analog Output: 0–12 V / 50 mA
• Switching Relay: 24 V / 2 A
• Connector: 32-pole European card format
• Compatible Pickup: Rheintacho O Dg 18b, ID-NR 1103743
• Application: Marine Propulsion & Engine Speed Monitoring
• Condition: Tested
