PR ELECTRONICS 2229 Switchmode Voltage Regulator

The PR ELECTRONICS 2229 is a switchmode voltage regulator designed to provide an adjustable DC output for measurement systems, sensors, transmitters and other control equipment. The regulator accepts AC or DC input and provides an adjustable 5–24 VDC output with maximum 40 W output power. It uses a standard 11-pole relay socket and includes short-circuit and thermal overload protection. PR Electronics has discontinued the 2229 series, making available units suitable for replacement and maintenance requirements. WAVETECH MARITIME supplies the PR ELECTRONICS 2229 for marine and industrial automation applications.

• Brand: PR ELECTRONICS
• Model: 2229
• Product Type: Switchmode Voltage Regulator
• Input: AC or DC
• Adjustable Output: 5–24 VDC
• Maximum Output Power: 40 W
• Maximum Output Current: 2.5 A at 5/12/15 VDC; 1.7 A at 24 VDC
• Mounting / Connection: Standard 11-pole relay socket
• Protection: Short-circuit and thermal overload protection
• Operating Temperature: -20°C to +60°C
• Protection Degree: IP30
• Status: Discontinued by manufacturer
