MURR ELEKTRONIK MCS20-115-230/24 85063 Switch Mode Power Supply

The MURR ELEKTRONIK MCS20-115-230/24 is a Power+ Series single-phase switch mode power supply, identified by Article No. 85063. Available product records specify a 100–240 VAC input and 24 VDC, 20 A SELV output.

• Brand: MURR ELEKTRONIK
• Product Series: Power+ Series
• Model: MCS20-115-230/24
• Article No.: 85063
• Product Type: Switch Mode Power Supply
• Supply Type: Single-phase
• Input: 100–240 VAC
• Input Frequency: 50/60 Hz
• Input Current: 5.5–2.4 A
• Input Terminals: L / N / PE
• Output Voltage: 24 VDC
• Output Current: 20 A
• Output Type: SELV
• Enclosure Rating: IP20
• Input Wire Size: Up to 2.5 mm² / 14 AWG
• Input Terminal Tightening Torque: 0.4–0.5 Nm
• Output Wire Size: Up to 4 mm² / 10 AWG
• Output Terminal Tightening Torque: 0.5–0.6 Nm
• Insulation Temperature Rating: 75°C
• Operating Temperature Marking: T60°C
• UL Temperature Marking: T40°C
• Weight: Approximately 2.88–2.90 kg, depending on supplier record
• Exact dimensions: Not independently verified
• Mounting configuration: Not independently verified
• Manufacturer status: Listed by Radwell as discontinued; verify replacement requirements before procurement.
