BERGHOF CONTROL QAIO-16-4-A-213740080-01008 VER-0011 Analog Extension Module

The BERGHOF CONTROL QAIO-16-4-A is an analog I/O extension module for compatible BERGHOF CANtrol automation systems. BERGHOF documentation identifies the QAIO 16/4-A as a local extension module with an E-Bus interface, providing 16 analog current inputs and 4 analog voltage outputs.

• Brand: BERGHOF CONTROL / Berghof Automationstechnik
• Product Family: QAIO
• Model: QAIO-16-4-A
• Part Number: 213740080-01008
• Version: VER-0011
• Product Type: Analog I/O Extension Module
• System: BERGHOF CANtrol
• Bus Interface: E-Bus
• Analog Inputs: 16
• Analog Input Type: Current
• Analog Input Range: 0–20 mA
• Analog Input Resolution: 12 bit
• Analog Outputs: 4
• Analog Output Range: ±10 V
• Analog Output Resolution: 12 bit
• Reference Voltage: +10 V / 5 mA reported for the QAIO 16/4-A family
• I/O Isolation: Analog I/O optically isolated against the E-Bus
• Connection: 4-pin signal connection with 5 × 18-pin plugs specified in Berghof documentation
• Function: Local extension of automation-system analog I/O
• Mounting: E-Bus extension module
• Exact current-input electrical limits: Configuration/documentation dependent
• Exact output current rating: Not independently verified for this exact VER-0011 unit
• Supply requirements: Not independently verified for this exact variant
• Dimensions: Not independently verified for this exact VER-0011 unit
• Weight: Not independently verified
• Firmware compatibility: Configuration-dependent
• Replacement Note: Match QAIO-16-4-A, 213740080-01008, and VER-0011 markings before replacement.
