B&R AUTOMATION X20DO6529 Digital Output I/O Module
Quality Tested
Worldwide Shipping
Secure Packaging
Expert Support
Product Overview
WAVETECH MARITIME supplies B&R AUTOMATION X20DO6529 Digital Output I/O Module with 6 isolated relay outputs for compatible X20 automation and control systems.
- Brand: B&R AUTOMATION
- Model / Material Number: X20DO6529
- Product Type: Digital Output I/O Module
- Number of Outputs: 6
The B&R AUTOMATION X20DO6529 is an X20 digital output I/O module featuring six single-channel isolated relay outputs with normally open contacts. B&R specifies the module for switching applications involving 30 VDC / 115 VAC loads.
Key Features
- Brand: B&R AUTOMATION
- Model / Material Number: X20DO6529
- Product Type: Digital Output I/O Module
- Number of Outputs: 6
- Output Type: Relay
- Contact Type: Normally open
- Output Isolation: Single-channel isolated
- Nominal Voltage: 30 VDC / 115 VAC
- Maximum Voltage: 125 VAC
- Maximum Switching Voltage: 110 VDC / 125 VAC
- Nominal Output Current: 1 A at 30 VDC / 0.5 A at 115 VAC
- Total Nominal Current: 6 A at 30 VDC / 3 A at 115 VAC
- Maximum Switching Capacity: 30 W / 62.5 VA
- Maximum Inrush Current: 2 A per channel
- Switching Delay: ≤4 ms
- Bus Power Consumption: 1.1 W
- Protection Rating: IP20
- Operating Temperature: −25 to +60°C horizontal; −25 to +50°C vertical
- B&R ID Code: 0x2019
- Mandatory Terminal Block: X20TB12
- Compatible Bus Modules: X20BM11 / X20BM15
- Marine Approvals: DNV, CCS, LR, KR, ABS, BV
- Brand: B&R AUTOMATION
- Model: X20DO6529
- Condition: Used
- Application:
- B&R X20 PLC systems
- Digital relay output control
- Marine automation
- Shipboard control systems
- Machinery automation
- Engine-room automation
- Motor and actuator control
- Alarm and signaling systems
- Industrial automation
- Marine control cabinets
- Replacement and maintenance of B&R X20 systems
- Availability: Subject to stock confirmation
