B&R AUTOMATION X20AT2222 Temperature Input I/O Module
Quality Tested
Worldwide Shipping
Secure Packaging
Expert Support
Product Overview
WAVETECH MARITIME supplies B&R AUTOMATION X20AT2222 Temperature Input I/O Module with 2 inputs for Pt100 and Pt1000 resistance temperature measurement.
- Brand: B&R AUTOMATION
- Model / Material Number: X20AT2222
- Product Type: Temperature Measurement I/O Module
- Number of Inputs: 2
- The B&R AUTOMATION X20AT2222 is an X20 temperature measurement I/O module providing two inputs for Pt100 or Pt1000 resistance temperature sensors. Each channel can be configured for the required sensor type, making the module suitable for monitoring temperature in machinery and process-control applications.
Key Features
- Brand: B&R AUTOMATION
- Model / Material Number: X20AT2222
- Product Type: Temperature Measurement I/O Module
- Number of Inputs: 2
- Sensor Types: Pt100 / Pt1000
- Measurement Range: −200 to +850°C
- Connection: 2-wire or 3-wire
- Measurement Type: Resistance measurement with constant-current supply
- ADC Resolution: 16-bit
- Measuring Current: 250 µA ±1.25%
- Resistance Range: 0.1–4500 Ω / 0.05–2250 Ω depending on gain
- Filter: Configurable, 1–66.7 ms
- Channel-to-Bus Isolation: 500 Veff
- Protection Rating: IP20
- Bus Power Consumption: 0.01 W
- Internal I/O Power Consumption: 1.1 W
- B&R ID Code: 0x1BA6
- Compatible Bus Modules: X20BM11 / X20BM15
- Terminal Blocks: X20TB06 / X20TB12
- Operating Temperature: −25 to +60°C horizontal; −25 to +50°C vertical
- Marine Approvals: DNV, CCS, LR, KR, ABS, BV
- ATEX: Zone 2, II 3G Ex nA nC IIA T5 Gc
- Brand: B&R AUTOMATION
- Model: X20AT2222
- Condition: Used
- Application:
- B&R X20 PLC systems
- Pt100 temperature monitoring
- Pt1000 temperature monitoring
- Engine-room automation
- Marine machinery monitoring
- Shipboard automation
- Industrial temperature measurement
- Motor and bearing temperature monitoring
- Process temperature monitoring
- Marine control cabinets
- Automation system maintenance
- Availability: Subject to stock confirmation
